How Nepalese Engineers Used A Single Phantom Drone to Map 138km of Roads

The project envisioned the concept of a digital inventory for data management and monitoring.

June 22nd, 2020

Governments, international organizations, companies and even national NGOs like to hire foreign experts to carry out drone surveys. Many assume that local expertise in professional, high-quality aerial surveys doesn't exist locally. Others aren't bothered by the fact that foreign experts do not understand the local languages, cultures or contexts of the communities they are parachuted into. In some cases, foreign experts are hired because they have expensive long-range drones, which are deemed essential for larger surveys. The project below directly counters this Western-centric mindset.


By Biplav Pangeni, Uttam Pudasaini, Bibek Singh, and Darpan Pudasaini of Nepal Flying Labs

This is the story of collaboration, innovation, and dedication, where a team of young engineers from Nepal challenged the status quo and, for the first time, carried out the longest drone survey in Nepal, which took 28 days to complete. The survey was carried out with 249 flights using a single DJI Phantom 4 Pro to capture 78,000 images surveying the 138 km Madan Bhandari National Highway. This highway connects two districts of Nepal: Sindhuli (133 km east of Kathmandu) and Udayapur.

In June 2019, the Department of Roads under the Ministry of Physical Infrastructure and Transport released a call for proposals to survey 138 km of road section using drones. This project had two primary objectives:

  1. Carry out the aerial survey of the road section using drones.
  2. Develop a digital inventory of the road section where the authorities could visualize the output maps and profile cross-section diagrams under the same platform.

DigiNirman, a civil engineering technological consulting firm in partnership with Dronepal, under the guidance of Nepal Flying Labs for project design and planning, successfully carried out the project with the best utilization of available resources. Together, they proved that even smaller drones can achieve challenging goals with superior resolution and outputs when projects are well planned.

The team only had one DJI Phantom 4 Pro with which they operated up to 12 flights a day, capturing up to 2500 images daily. The field survey team was traveling continuously as they conducted the aerial missions, and the batteries needed to be changed frequently. They continued doing this for 26 days, and with the help of 249 successful flights, they were able to reach the ceiling of 78,000 images.

The primary outputs of the project were:

  • High-resolution aerial images
  • A detailed map of the entire road section: high-resolution orthophoto, contour maps of 1m contour intervals, and a complete top map.
  • Profile and cross-section maps at each chainage
  • A web-based road inventory to store images and different outputs of the project

About the Web-Based Inventory

The common practice of any surveying work in Nepal involves surveying, data collection, and submission of data from consultants to the clients/projects most often in hard copy formats and sometimes in soft copy formats through the use of pen drives/hard drives. What does not happen is effective construction monitoring, especially in a project like this, which is stretched in about 135 KM. It becomes quite challenging to cover a site that is spread in about 135 KM, let alone minutely monitor the construction activity.

This project thus envisioned the concept of a digital inventory for data management and monitoring. A web-based digital tool was also developed so that all the datasets captured under this project, along with the generated outputs, could be appropriately stored and retreated anytime when the project requires it. Its further goal is to create an interface that can also be a tool for asset management. It’s important to update information regarding the condition of the road pavement and road structures so that maintenance activities can be planned without any delay. Such smooth management requires the flow of information, and the digital interface built under this project could provide all those details in one location.

This project showed that the stereotyping of smaller drones changes as they can also perform large scale substantial tasks. This also showed the data processing capacity of new generation analysts that can work with 100k high-resolution images.

The project was full of several challenges, and the team applied different strategies to overcome it.

Challenges:

  • Securing permissions from multiple districts: The project has been challenging since its start. The 138km stretch road touches two districts of Nepal; Sindhuli and Udaipur require permission to fly drones from each district office.
  • Mechanical challenges: Overheating of the drone and more extended cooling period due to the high surrounding temperature.
  • Risk of accidents as vehicles in high speed
  • Establishing and making sure the GCPs in-ground stays longer: A lot of time was consumed in stabilizing and protecting the GCP, from Local residents taking away the GCP to Livestock tampering the GCP.
  • Community engagement and response: Lack of local exposure to the technology; in many places, the project team had to spend hours talking to the community people, explaining about drones.
  • Logistical challenges:
    • Drone batteries charging problems due to lack of electricity in various places
    • The frequent cut of power affecting the charging of drone batteries
  • Data management issues: storing and transfer of a large set of data.
  • Natural conditions and terrain: River flooding resulting in delayed flights, high-speed wind affecting the drone, forcing it downwards, and poor daylight condition due to cloud coverage.
  • Flight planning: This was extremely challenging due to uneven terrain: two sides of the road being on different levels.
  • Processing capacity: There were nearly 75,000 images for 134km of road stretch and the technical team only had two workstations.

Strategies applied to overcome the challenges:

  • Support from the department of roads and Engagement with the locals: The department of roads provided a recommendation letter. The project team visited both the district coordination office, district administration office, and managed to secure the permissions. They carried out the survey starting from Bhiman, Sindhuli.
  • Use of motorcycles: Motorcycles were used to commute while operating the flights to ensure quick progress in the field works.
  • Battery swapping and rapid charging: Quick battery swapping was a necessity for continuous flights. Each battery was given a code, and with initial 40 flights, the battery health and performance were recorded, which was used to select the right battery for each mission. The snack stall or nearest resident was chosen for charging of batteries, which were charged after every two flights.
  • Parallel processing: The team had to establish a parallel processing mechanism for such a large number of images. For that, they sent the pictures to a processing station located at Kathmandu, every other day. Parallel processing needed for efficient completion of the project. The team used the Pix4Dmapper for data processing and the Pix4Dcapture for all mission planning.

Swapping of six regularly charged batteries and three interval flights led to successful field data acquisition. DJI Phantom 4 Pro stood strong and sturdy throughout the journey with no physical or firmware problems.

Our pilots in the project worked tirelessly to achieve the goal and had lots of experiences to share, including:

"The benefits of flying a drone compared to a ground survey is enormous. We surveyed 134 kilometers (total area of 16,387,985 sq.m.)that’s 230 kilometers of fencingin just about a month. On foot, an athletic and organized surveyor could cover only around two kilometers of the fence a day, as it is often surrounded by dense vegetation. Furthermore, the only output would have been the shapefile, while thanks to Pix4D, we were able to deliver not only that but orthomosaics and point clouds which can be used for dozens of other projects."

~Bibek Sapkota, a geologist by education & a drone pilot/data analyst by profession

The Way Forward

The output of the project has already been submitted. This was an important lesson for the team, and we believe that this can be meaningful learning for the other drone professionals in the drone community as well. As the project has successfully proven the potential of professionally handling a large scale mapping and survey with a small consumer drone. Also, for the Department of Roads, multipurpose outputs have been provided.

Construction monitoring is one key aspect that this project addressed. Data obtained from the drone survey could be used by the client to check if the contractors have followed design criteria in every chainage or not. The location of the as-built road structures like bridges, culverts could be checked and tallied with the design. Also, The geometry of the as-built alignment could be checked by overlaying CAD design drawing in the orthophotos, and differences in the as-built scenario and design scenario could be spotted.

Further, The project has also tried to introduce the concept of multipurpose datasets during a survey assignment. The same outputs generated from this project could also be utilized for several purposes other than road expansions. In the future, these data can be used not just for knowing the road’s health but also for multiple purposes such as Realtime Construction Monitoring, Bridge Site Investigation, Realtime Traffic Safety Simulation, Construction Material Volumetric Calculation, and Road Asset Inventory.

If not for this technology, clients would have required a lot of time to figure out construction discrepancies and, in many cases, would never have figured out the errors. Building the web-based digital interface where the orthophotos and as-built inventory was uploaded, this project paved a unique way of transparency. The digital interface could be used by all stakeholders and the public to track the progress of the project, check for construction discrepancies, question the concerned authorities about the variations. Thus, this drone survey completely changed the game for all stakeholders of the project. Government agencies should embrace this innovative technology more often to give it a chance to bloom.
